GATE VALVE SIZE 8 IN, RATING ASME 600 PRODUCT TYPE SAF-T SEAL ®NOMINAL VALVE SIZE 8 IN (200 MM)PRESSURECLASS RATING ASME600 (100 PN)END TO END STANDARD TRIM T24NACE MODEL C6 BEND CONNECTIONFLANGED RAISED FACE FLANGEFINI...

MAGNETIC WITNESS ASME

BLIND:PIPE TYPE:SPECTACLESIZE:8 IN RATING:600 CL THCK:28.4 MM MATL:CS SPEC:A516 GRADE:70 RF, FIGURE 8 BLANK, IAW ASME B16.48

BLIND:PIPE TYPE:SPECTACLESIZE:4 IN RATING:600 CL THCK:15.7 MM MATL:CS SPEC:A516 GRADE:70 RF, FIGURE 8 BLANK, IAW ASME B16.48

STUD AND NUTS, SIZE 5/8 " X 4 3/4 ", STUDS ASTM A193 GR B7, CAD. PLATED PER ASTM B766, CL8 TYPE 2 ASME B16.5----NUTS ASTM A194 GR 2H, HH. SEMI-FINISHED, CAD. PLATED PER ASTM B766, CL8 TYPE 2

WIKA Instrument Corp 233.30 4 25BAR 1/2 L Line Item Notes: *Mfr: WIKA Instrument Corp *Mfr pn: 50355201 Type 23X.30 - Solid-front Safety Case Pressure Gauges Model: 233.30 Specifcations according to data sheet: PM...

233.50.2.5" 250 bar 1/2 NPT lower mount Type 23X.50 - SS Case - Pressure Gauges Series Model: 233.50 Specifcations according to data sheet: PM 02.02 Measuring System: Stainless Steel Case flling: with Nominal size...

GASKET SPRL WND 16IN X 150LB GASKET SPIRAL WOUND 16 IN NOM 150 LB FLG 15 3/4 IN INNER RIN G ID 16 5/ 8 IN ID 18 1/4 IN OD 20 1/4 IN RING OD.175 IN THK MATL 316 SSTLWINDINGS 18-8 CHR NI,3 PCT MOLY FLEX GRAPH FI LLED 1/...

GASKET SPRL WND 2IN X 900LB GRAPHITEGASKET SPIRAL WOUND 2 IN NOM 900 LB FLG 2 1/16 IN INNNER RIN G ID 2 5/ 16 IN ID 3 3/8 IN OD 5 5/8 IN RING OD .175 IN THK M ATL 316L SSTL WINDINGS FLEX GRAPH FILLED 1/8 IN THKCSTL C...

GASKET SPRL WND 10-3/8IN X 9-3/16IN GRAP GASKET SPIRAL WOUND 8`NOM 300LB FLANGE 8-1/2` INNER RING ID 9-3/16`ID 10-3/8`OD 12-1/8` RING OD 316L STAINLESS STEEL L WINDINGS FLEX GRAPH FILLED 1/8` THICK CARBON STEEL CENT...

STUDBOLT 1IN 8IN LONG ASME SA197 GR B7 STUD BOLT 1IN 8IN LONG ASME SA197 GR B7 C/W 2 X HEX NUTS BLUE XYLAN 1070 COATED

STUDBOLT 1INx8IN W/TWO NUTS ALL COATED STUDBOLT 1IN X 8IN LONG ASME SA193B7 STUD W/TWO SA194 2H NUTS XYLAN 1070 COATED.
